240KW DC EV Charging Station OCPP1.6 Chargepoint DC Fast Charger Locations

Product Details

Place of Origin: sichuan

Brand Name: Xidao

Certification: GB

Model Number: DC-240KW

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: negotiate

Packaging Details: Wooden case packaging

Delivery Time: 15-30 work days

Payment Terms: L/C, T/T

Supply Ability: 5000 per month

Get Best Price
High Light:

240KW DC EV Charging Station

,

IP54 DC EV Charging Station

,

OCPP1.6 chargepoint dc fast charger locations

Product Name:
240KW DC EV Charging Station
Output Voltage:
200~750V
Output Rated Power (KW):
240KW
Voltage Stabilization Accuracy:
≤±0.5%
Flow Stabilization Accuracy:
≤±1%
Auxiliary Power:
12V/24V
IP Grade:
IP 54
Product Name:
240KW DC EV Charging Station
Output Voltage:
200~750V
Output Rated Power (KW):
240KW
Voltage Stabilization Accuracy:
≤±0.5%
Flow Stabilization Accuracy:
≤±1%
Auxiliary Power:
12V/24V
IP Grade:
IP 54
240KW DC EV Charging Station OCPP1.6 Chargepoint DC Fast Charger Locations





GB/T 240 KW Commercial Fast DC EV Charging Station OCPP1.6 IP 54





Introduction



The charger is professionally designed for the charging needs of lithium power battery electric vehicles. The product adopts modular design, can be used in parallel with multiple modules, and has good fault tolerance. With CAN fieldbus, it can communicate with Battery Management System BMS and power background monitoring system in real time, so as to monitor, protect and optimize the charging process of lithium power battery in an all-round way. The operation interface adopts humanized touch screen, with simple interface and convenient operation.



Product Parameters



Product name DC EV Charging Station
Input voltage AC 380V ±10%
AC power input connection 3P+N+PE
Operating Frequency 50hz
Power Factor >0.99
Output rated power 240A
Output Current 0-240
Current limit adjustable range 10%~100%
Current error ≤1%
Current accuracy ≤±1%
Module Unbalance ≤5%
Ripple coefficient ≤±5%
Charge gun cable length 2 guns/guns 7m cable
Auxiliary power supply 12V/24V
Display method Touch screen
Protection level IP54
Cooling method Forced air cooling
mounting method Floor mounting
Reference size 800*1050*2000



Main features



Main features of DC fast chargers for electric vehicles



1. High efficiency: efficiency up to 94%, can save users electricity and reduce heat loss

2. High power density: small size, saving space and adapting to the development direction of future charger

3. Input high voltage shock resistance: greatly improves system reliability.

4. Modular design: multiple modules work in parallel, with strong fault tolerance, a module failure does not affect the use of the whole machine, it can be convenient to repair and replace a single module.



Details Images





240KW DC EV Charging Station OCPP1.6 Chargepoint DC Fast Charger Locations 0

240KW DC EV Charging Station OCPP1.6 Chargepoint DC Fast Charger Locations 1

240KW DC EV Charging Station OCPP1.6 Chargepoint DC Fast Charger Locations 2

240KW DC EV Charging Station OCPP1.6 Chargepoint DC Fast Charger Locations 3



Company Profile



Chengdu Xiangdao Technology Co., Ltd. is a company specializing in the overall solution of development, design sales and operation of new energy, including electric vehicle charging piles, fast charging stations, solar photovoltaic power generation systems, solar application products, etc..

We are committed to providing total solutions for the application of new energy technologies.

We have 5 major product lines.

1. DC charging pile: 30KW~360KW DC charging pile

2. AC charging pile: 7KW/11KW/22KW/42KW AC charging pile

3. Portable charger gun: 3.5KW/7KW portable charging guns.

4. Solar power generation components: photovoltaicpanels, controllers, inverters, energy storage batteries a full set of power generation components.

5. Solar energy applicationproducts: solar panel, solar reding lights, solar tents, solar street lights, solar . . monitoring systems, etc..



240KW DC EV Charging Station OCPP1.6 Chargepoint DC Fast Charger Locations 4

NOTE:

1- OEM supported.

2- Any requirement please contact us to talk about the details.

3- We will reply you for your inquiry in 24 hours.

4- If you have any questions about the charger, please contact us.

5- The above for reference only, final price decide by the charger KW, please contact us to get the correct quote.
