3.3VDC Charger PCB Board SPI Communication CCS Charge Controller

Product Details

Place of Origin: sichuan

Brand Name: Xidao

Certification: GB/T

Model Number: PCB-M1

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: negotiate

Packaging Details: Wooden case packaging

Delivery Time: 15-30 work days

Payment Terms: L/C, T/T

Supply Ability: 5000 per month

Get Best Price
High Light:

13.56MHz charger pcb board

,

3.3VDC charger pcb board

,

SPI communication ccs charge controller

Product Name:
PCB-M1
Supply Voltage:
3.3VDC ±5%
Rated Current:
<200mA
Card Reading Distance:
<5cm
Card Type:
M1
Operating Temperature:
-40℃~+50℃
Size:
65mm*45mm*10mm
Product Name:
PCB-M1
Supply Voltage:
3.3VDC ±5%
Rated Current:
<200mA
Card Reading Distance:
<5cm
Card Type:
M1
Operating Temperature:
-40℃~+50℃
Size:
65mm*45mm*10mm
3.3VDC Charger PCB Board SPI Communication CCS Charge Controller





GB/T PCB M1 Card 3.3VDC PCB Board 13.56MHz <200mA With SPI Communication





Product introduction



The card reader is an M1 card reader with a frequency of 13.56MH2, accessories for charging pile scheme,
Realize swipe card identification and offline e-wallet functions.



Product Parameters



Supply voltage 3.3VDC ±5%
Rated current <200mA
Card reading distance <5cm
card type M1
Operating temperature -40℃~+50℃
storage temperature -40℃~+80℃
environment humidity ≤ 95%
size 65mm*45mm*10mm



Function Introduction



Small size, large read and write distance, SPI communication



Details Images



3.3VDC Charger PCB Board SPI Communication CCS Charge Controller 0
