Product Details
Place of Origin: sichuan
Brand Name: Xidao
Certification: CE
Model Number: XD-DC-1600KW
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: negotiate
Packaging Details: Wooden case packaging
Delivery Time: 50 work days
Payment Terms: L/C, T/T
Supply Ability: 500 per month
Model: |
Super Charging Ev Charger DC 900KW |
Dimension Of Main Cabinet: |
2183*1163*1056.4mm |
Dimension Of Split Cabinet: |
1815*772*508mm |
AC Input Voltage: |
380V±15% |
AC Input Frequency: |
45Hz～66Hz |
Rated Power: |
Pe≤450kW |
Output Voltage: |
200-1000vdc (300-1000vdc Constant Power) |
DC Output Current: |
Air-cooled Charging Subcabinet:0~200A(ccs1/ccs2)0~250A(GB/T)Liquid-cooled Superchargingsub-cabinet:0~800A |
Protection Level: |
IP54 |
Shell Impact Resistance Rating: |
IK10 |
Charging Gun: |
1 Liquid-cooledsupercharger(900KW),7 Air-cooledfast Chargers,(60KW~180KW) 5m |
Model: |
Super Charging Ev Charger DC 900KW |
Dimension Of Main Cabinet: |
2183*1163*1056.4mm |
Dimension Of Split Cabinet: |
1815*772*508mm |
AC Input Voltage: |
380V±15% |
AC Input Frequency: |
45Hz～66Hz |
Rated Power: |
Pe≤450kW |
Output Voltage: |
200-1000vdc (300-1000vdc Constant Power) |
DC Output Current: |
Air-cooled Charging Subcabinet:0~200A(ccs1/ccs2)0~250A(GB/T)Liquid-cooled Superchargingsub-cabinet:0~800A |
Protection Level: |
IP54 |
Shell Impact Resistance Rating: |
IK10 |
Charging Gun: |
1 Liquid-cooledsupercharger(900KW),7 Air-cooledfast Chargers,(60KW~180KW) 5m |
900KW Split Liquid-Cooled Super DC Charging Stack CCS Stype2 IEC 62196-3 IEC 61851 Charge Mode 4
Product Introduction
The DC900kwI liquid-cooled fast charging stack is a system that integrates intelligent charging and advertising business. It mainly includes
1,Intelligent control host: intelligent control and intelligent distribution
2,Liquid-cooled charging post: equipped with liquid-cooled charging gun with maximum power of 900KW, specially designed for fast charging of high-power vehicles, 15 minutes full. It follows the allocation principle of first-come, first-served.
3,Air-cooled charging post.:Single gun, minimum 60KW, maximum 180KW configuration.
4,Advertising screen: large intelligent screen, which can remotely control the advertising broadcast and increase the advertising revenue of the charging post.
During the waiting time of charging, it happens to be a good time for advertising implantation. When more and more charging piles are built, their advertising effect will be better and better.
This kind of advertising screen can be shaped separately or designed integrally with the charging pile.
Product Highlights
1. The liquid cooling technology is adopted to realize the miniaturization and softness of the liquid cooling cable, which can carry a current of 800A, and the temperature of the charging gun terminal is lower than 55 ℃; the cooling liquid is an organic synthetic liquid, which will not freeze at minus 45 ℃; cooling The source module has monitoring and alarming devices for the working pressure, flow and temperature of the coolant.
2. It can meet the needs of high-power and fast charging of electric vehicles, realize the full charge of the vehicle within 10 minutes, and solve the customer's pain point of long charging time.
3. Meet the charging requirements of all models and different powers, and dynamically match the charging power required for the electric vehicle connected to any terminal;
4. Adopt intelligent charging module, which has the advantages of high power, high efficiency, low harmonics, and high intelligence, especially suitable for high-power charging of electric vehicles in public transportation;
5. According to the charging demand issued by the charging vehicle BMS, the charging power is dynamically allocated, thereby improving the utilization rate of charging equipment and realizing highly integrated management: integrated power conversion, dynamic power distribution, station-level monitoring, orderly charging management, new energy power generation And energy storage system access, cooling control, integrated wiring;
6. Strong scalability (corresponding charging modules can be expanded to meet charging needs), energy saving and high efficiency (efficiency reaches over 96%).
7. One main cabinet can be connected to multiple charging terminals (sub-cabinet) to meet different operational needs.
8. Standard 4G module, charging operation: swipe card / scan code;
9. Payment method: RFID card.
Company Profile
FAQ
Q: How long is your delivery time?
For charging posts, it is usually 3-10 days. If there is no stock, the production lead time is determined according to the order quantity. High-power DC char- ging posts usually need to be customized according to the customer's technical parameters.
Q: How long does it take to customize the prototype?
For charging piles, the prototype time is usually 7 days.
For DC charging post, the prototype time is usually 15 days.
For high power fast charging station, the technical parameters need to be
determined before production, and the prototype time is usually 30 days.
Q: How to guarantee the service?
Our products are divided into two categories: household and commercial.
For home chargers, we provide standardized service: 1 year warranty + remote installation and usage guidance + video installation tutorial
For commercial chargers, we not only provide standardized services for charging piles, but also provide payment software docking services for opera
ting companies.
Q: How do you guarantee the quality of your products?
The charging post products we sell have passed GB certification in China and CE certification in EU. For some other countries, the relevant certifications are
in progress.
Q: How do you guarantee the quality of your products?
The charging post products we sell have passed GB certification in China and CE certification in EU. For some other countries, the relevant certifications are
in progress.
NOTE:
1- OEM supported.
2- Any requirement please contact us to talk about the details.
3- We will reply you for your inquiry in 24 hours.
4- If you have any questions about the charger, please contact us.
5- The above for reference only, final price decide by the charger KW, please contact us to get the correct quote.
