Product Details
Place of Origin: sichuan
Brand Name: Xidao
Certification: SAE J1772
Model Number: AC-BG1-11W-LT
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: negotiate
Packaging Details: Wooden case packaging
Delivery Time: 15-30 work days
Payment Terms: L/C, T/T
Supply Ability: 5000 per month
Product Name: |
22KW Wallbox EV Charger |
Rated Input: |
380V32A |
Rated Output: |
380V32A |
Input Frequency: |
50Hz±1% |
Output Power: |
22KW |
Operating Temperature: |
-1℃~+60℃ |
Relative Humidity: |
No More Than 85% |
Product Name: |
22KW Wallbox EV Charger |
Rated Input: |
380V32A |
Rated Output: |
380V32A |
Input Frequency: |
50Hz±1% |
Output Power: |
22KW |
Operating Temperature: |
-1℃~+60℃ |
Relative Humidity: |
No More Than 85% |
CE Home Version 22KW AC Wallbox EV Charger IEC 61851-2017 / IEC62196-2:2016
Product Introduction
Have display interface which can be customized
Product Parameters
| Product name | Wallbox EV Charger | ||
| Product type | Home version | ||
| Shell material | Black tempered glass panel, PC body | ||
| Equipment dimension | 310*161*79.8mm (L*W*H) | ||
| Wiring method | Getting in and going out from the bottom | ||
| Equipment weight | <6kg | ||
| Gun length | 5m | ||
| Input voltage | 380V | ||
| Input frequency | 50Hz | ||
| Max. power | 22KW | ||
| Output voltage | 380V | ||
| Output current | 32A | ||
| Applicable scene | Indoor / Outdoor | ||
| Operating temperature | -30℃ ~ +55℃ | ||
| Operating humidity | 5% ~ 95%, without condensation | ||
| Height above sea level | <2000m | ||
| Protection level | IP65 | ||
| Cooling method | Natural cooling | ||
| Safety certification | SAE J1772 | ||
| MTBF | 100,000 hours | ||
| Special protection | UV protection design | ||
| Safety design | Over-voltage protection, under-voltage protection, overload protection, earth leakage protection, grounding protection, over-temperature protection, low-temperature protection, lightning protection |
||
Details Images
FAQ
Q: How long is your delivery time?
For charging posts, it is usually 3-10 days. If there is no stock, the production lead time is determined according to the order quantity. High-power DC char- ging posts usually need to be customized according to the customer's technical parameters.
Q: How long does it take to customize the prototype?
For charging piles, the prototype time is usually 7 days.
For DC charging post, the prototype time is usually 15 days.
For high power fast charging station, the technical parameters need to be
determined before production, and the prototype time is usually 30 days.
Q: How to guarantee the service?
Our products are divided into two categories: household and commercial.
For home chargers, we provide standardized service: 1 year warranty + remote installation and usage guidance + video installation tutorial
For commercial chargers, we not only provide standardized services for charging piles, but also provide payment software docking services for opera
ting companies.
Q: How do you guarantee the quality of your products?
The charging post products we sell have passed GB certification in China and CE certification in EU. For some other countries, the relevant certifications are
in progress.
